ESD Work Bench

ESD Work Bench Specification

Regional Style
Indian Standard

Technology
ESD Protection Technology

Design
Modular with Shelves and Footrest

Width
1200 mm to 1800 mm (customizable)

Assembly
Knock-down, Easy Assembly Required

Inflatable
NO

Height
750 mm to 900 mm (adjustable)

Metal Type
Mild Steel

Furniture Type
ESD Work Bench

Material
Mild Steel, ESD Laminated Board

Metals Type
Mild Steel

Wood Type
Engineered Wood (for Board)

Plastic Type
ABS (for fittings)

Appearance
Modern Industrial

Folded
No

Stackable
No

Color
Light Grey with Blue Accents

Weight
Approx. 60-90 kg (varies with size)

Finish
Powder Coated

Feature
Anti-static, Durable, Adjustable Height, Heavy Duty

Edge Protection
ESD Safe PVC Edging

Applications
Electronics assembly, PCB handling, Repair workstations

Earth Point
Integrated ESD grounding point

Load Capacity
Up to 200 kg

Top Surface Material
ESD Laminated Anti-Static Board

Shelves
Adjustable upper shelf included

Leg Type
Square tubular steel legs with levelling feet

Drawer/Cabinet
Optional locking drawers/cabinets

ESD Work Bench Trade Information

Minimum Order Quantity
1 Unit

Supply Ability
10 Units Per Week

Delivery Time
1 Week

About ESD Work Bench

The ESD word workbench is crucial for different electronic applications. The said product is suitable for its effective use as an assembly in the electronic industry. It has been designed as an individual work stations in clean rooms, warehouses, factories, and some controlled areas. ESD word workbench is one of the central elements that comes within an ESD protected area. The said products are suited for electronics production and advanced repair facility. Its usage will ensure safe uses on non-ESD dissipative surface. This worktable is widely used for production test areas, research & development laboratories, repair areas and service areas.

Specification

Number Of Drawer	4 Drawer
Model Name/Number	J10
Material	MS
Brand	HV Engineering
Usage/Application	Hospital

Superior ESD Protection for Electronics Work

Outfitted with ESD-laminated anti-static surfaces and edge-protected with ESD-safe PVC, this work bench ensures safety when handling sensitive PCBs and electronic components. Its integrated ESD grounding point offers reliable dissipation of static charges, minimizing the risk of damage during assembly or repairs.

Heavy-Duty Construction with Modular Flexibility

The bench is built from powder-coated mild steel, providing durability and strength up to 200 kg. Adjustable featuresincluding height, upper shelves, and optional storageallow customization for a wide range of work applications. Designed for easy assembly, the modular system adapts to various workspace needs.

FAQs of ESD Work Bench:

Q: How does the ESD work bench protect electronic components from static electricity?

A: The ESD work bench features an anti-static laminated top and ESD-safe PVC edging, which safely disperse static charges. An integrated grounding point allows the user to connect a wrist strap, maintaining a controlled discharge path to ground, thereby safeguarding sensitive electronic components.

Q: What types of applications is this ESD work bench suitable for?

A: This work bench is ideal for electronics assembly, PCB handling, and repair workstations. Its stable, anti-static surface and modular design make it a reliable choice for environments where static-sensitive devices are handled or assembled.

Q: When should the grounding point on the ESD bench be used?

A: The grounding point should always be used when working with static-sensitive electronic parts. Before starting assembly, repairs, or PCB handling, connect an ESD wrist strap or grounding wire to the integrated grounding point to ensure static charges are dissipated safely.

Q: Where can the ESD work bench be installed?

A: The work bench can be installed in electronic manufacturing facilities, R&D labs, repair centers, and any environment that requires ESD-safe workspaces. Its adjustable height and modular features accommodate a variety of workstations and workshop layouts.

Q: What is the assembly process for the ESD work bench?

A: The ESD work bench comes in a knock-down format for easy shipping and setup. Assembly involves fitting the square tubular steel legs, leveling feet, ESD laminated top, shelves, and optional drawers or cabinets, following the supplied instructions. Basic tools are required for assembly.

Q: How can the usage of optional drawers and shelves benefit my work process?

A: Optional locking drawers, cabinets, and adjustable upper shelves provide organized storage for tools, components, and documents. This modular storage enhances workflow efficiency by keeping essential items within easy reach and secured when not in use.
