Modular Belt Conveyor

Modular Belt Conveyor Specification

Belt Type
Modular Plastic Belt

Features
Modular design, Easy maintenance, Customizable length & width

Thickness
3 mm to 8 mm (belt)

Surface Finish
Powder Coated / Polished

Power Source
Electric

Material
Stainless Steel/Plastic Modules

Type
Modular Belt Conveyor

Structure
Frame with modular belt

Belt Conveyor
Yes

Roller Conveyor
No

Vertical Conveyor
No

Pneumatic Conveyor
No

Resistant Feature
Corrosion Resistant, Wear Resistant

Load Capacity
Up to 200 kg/m

Voltage
220-240 V

Power
0.37 kW to 2.2 kW

Speed
1-30 m/min (adjustable)

Usage & Applications
Packing, Sorting, Assembly, Food Processing, Pharmaceutical

Conveyor Length
Up to 30 meters

Installation
Floor Mounted

Drive Type
Motorized Central Drive

Operating Temperature
-10C to 60C

Belt Width
300 mm to 1200 mm (customizable)

Noise Level
Below 65 dB

Maximum Incline Angle
Up to 25 degrees

Modular Belt Conveyor Trade Information

Minimum Order Quantity
10 Meter

Supply Ability
1000 Per Day

Delivery Time
1 Week

About Modular Belt Conveyor

With our well deserved involvement with this space, we offer a huge scope of Modular Belt Conveyor to our significant customers. It is very vigorous and can be utilized in a large number of ways for pretty much every vehicle application. This gadget wear-safe and can even be utilized to ship item with sharp edges. Offered Modular Belt Conveyor can be utilized to ship items in an orderly fashion or through alters in height or course.

Customizable Design and Versatility

Tailor the conveyor system to fit your exact requirements with customizable belt widths (300 mm to 1200 mm) and lengths (up to 30 meters). Ideal for industries that demand flexibility, such as packaging, sorting, assembly lines, food processing, and pharmaceuticals, this modular design simplifies reconfiguration and expansion as business needs evolve.

Durability and Performance in Harsh Conditions

The conveyor is constructed using corrosion-resistant materials and a robust modular plastic belt, supporting temperature ranges from -10C to 60C. It reliably handles heavy loads (up to 200 kg/m) while maintaining low noise levels, ensuring operations are efficient and comfortable for workers even in challenging environments.

Easy Operation and Maintenance

Designed for straightforward floor installation and user-friendly maintenance, this conveyor system employs a motorized central drive and offers adjustable speeds between 1 and 30 m/min. The modular belt enables swift cleaning or replacement, reducing downtime and ensuring continuous productivity.

FAQ's of Modular Belt Conveyor:

Q: How can the Modular Belt Conveyor be customized for different applications?

A: The conveyor's belt width, length, and speed are customizable to accommodate various materials and operational needs. Belt widths from 300 mm to 1200 mm and lengths up to 30 meters make it versatile for packing, sorting, assembly, and food processing. You can also request tailored configurations based on specific space and workflow requirements.

Q: What materials and finishes are used in the construction of this conveyor?

A: The conveyor features a robust frame made from stainless steel and is equipped with modular plastic belt segments. Surface finishes include powder coating or polished stainless steel, enhancing durability and resistance to corrosion and wear, making it suitable for demanding environments.

Q: Where is the conveyor best installed, and is it suitable for all environments?

A: Designed as a floor-mounted solution, the conveyor is suitable for factories, processing plants, and assembly lines. Its corrosion-resistant materials and ability to operate between -10C and 60C make it ideal for both dry and humid conditions typical in food and pharmaceutical industries.

Q: What is the process for adjusting the speed and incline of the conveyor?

A: The conveyor features a motorized central drive with speed adjustments available between 1 and 30 meters per minute. The maximum incline angle is 25 degrees, allowing seamless adaptation to your operational needs. Speed adjustments can be made via integrated controls during installation or operation.

Q: How does the modular design benefit routine maintenance and repairs?

A: The modular belt and frame structure allow for quick replacement or cleaning of individual belt segments and components. This facilitates easier inspection, reduces downtime, and enhances the efficiency of routine maintenance compared to traditional conveyors.

Q: When should I consider using this modular belt conveyor instead of other conveyor types?

A: Choose this conveyor when you require a system with flexible dimensions, resistance to corrosion and wear, low maintenance, and suitability for moderate inclines and variable speed. It is especially beneficial for industries like food processing or pharmaceuticals where hygiene, durability, and adaptability are priorities.
